Kiosk Printer – TG2460

CHARACTERISTICS

Suitable for tough environments, down to -20°C up to +70°C

Available version with ejector

Illuminated paper bezel

Multi-position paper roll

Large paper roll: Ø 100 mm

Metal structure that provides increased rigidity for the printing mechanism and facilitates motor heat dissipation, resulting in improved stability and reliability over time

Improved distribution of the head-roller pressure, resulting in improved printing quality

APPLICATIONS:

Self-service kiosks

Banking machines

Gaming machines

Parking meters

Queue management systems

Vending machines

PrinterSet

CustomPowerTool

TECHNICAL SHEET

Printing Method Thermal with fixed head

Number of dots 8 dots/mm

Columns 32 - 42 - 56

Resolution 203 DPI

Printing (mm/sec) 140mm/sec

Character set PC437, PC850, PC860, PC863, PC865, PC858, PC866, GB2312

Printing Format Normal, height and width from 1 to 4, bold, negative, underlined, script, italic

Printing Direction Straight, 180°

Paper width 60 mm

Paper weight from 55 to 70 g/m²

Paper thickness from 60 to 80 μm

Roll Dimension 100 mm

Sensors Head temperature, paper jamming, paper presence, notch presence, optional: almost external paper end

Emulation Custom/POS, TGH

Interfaces RS232 + USB

Data Buffer 2 kB

Flash Memory 1 MB

Graphic Memory 2 logos of 448x584 dots

Drivers Windows

Virtual COM

Linux

Software Tools Status Monitor, PrinterSet, CustomPowerTool

Power supply 24V +/- 10%

Medium consumption 0.62A  (12.5% dots turned on)

MTBF 420,000 hours (electronic board )

Head Life 50Km/100M pulses

Operating temperature -20°C + 70°C

Dimensions 100x120(h)x93 mm (with front) - 118x80(h)x114 mm (with automatic cutter)

Weight 0.6 Kg
