Thermal Printer

Kiosk Printer – TL60

CHARACTERISTICS

Extremely compact: just 77mm high

Suitable for tough environments, down to -20°C up to +70°C

Multi-position paper roll holder: lower, top or rear position

Paper roll diameter up to 80 mm

Metal structure that provides increased rigidity for the printing mechanism and facilitates motor heat dissipation, resulting in improved stability and reliability over time

Improved distribution of the head-roller pressure, resulting in improved printing quality

APPLICATIONS:

Self-service kiosks

Banking machines

Gaming machines

Parking pay terminals

Queue management systems

Vending machines

SOFTWARE:
Remote status monitor

PrinterSet

CustomPowerTool

TECHNICAL SHEET

Printing Method Thermal with fixed head

Number of dots 8 dots/mm

Columns 24 - 32 - 44

Resolution 203 DPI

Printing (mm/sec) 140mm/sec

Character set PC437, PC850, PC860, PC863, PC865, PC858, PC866, VISCII (Option 0104: PC437, PC850, PC860, PC863, PC865, PC858, GB2312)  Printing Format Normal, height and width from 1 to 4, bold, negative, underlined, script

Printing Direction Straight, 180°

Paper width 60 mm

Paper weight from 55 to 80 g/m²

Paper thickness from 63 to 85 μm

Roll Dimension max 80mm

Sensors Head temperature, paper presence

Emulation Custom/POS, TGH

Interfaces RS232 + USB

Data Buffer 2 kB

Flash Memory 1 MB

Graphic Memory 2 logos 448x584 dot

Drivers Windows, Linux

Software Tools Status Monitor, PrinterSet, CustomPowerTool

Power supply 24V +/- 10%

Medium consumption 0.65A (12,5% dots on)

MTBF 172.000 hours (electronic board )

Head Life 50Km/100M pulses

MCBF 1,000.000 cuts

Operating temperature -20°C + 70°C

Dimensions 130(L)x105(W)x77(H)mm

Weight 0.800 Kg
