Kiosk printer – TK180

CHARACTERISTICS

Extremely Compact and Reliable

Full metal robust casing

BPP and BTP all-in-one

Cupps compliant and native AEA 2012 support

High speeds up to 200mm/sec

Interface: USB, RS232 and Ethernet

2 sides tear-off bar

Automatic ticket length detection

New metal paper roll holder

Full paper auto-loading without paper wasting

FOCUS ON:

Designed for small check-in desks where space is a major issue

Paper roll or fan fold tickets

Highly durable

Powerful processor inside

LCD blue backlit embedded display

APPLICATIONS:

Domestic airports

Small-sized check-in desks

Boarding desks

Mobile check-in desks

UHF

- FCC standard, fully compliant to the US telecommunication regulation FCC part 15 (902-928 MHz)

- ISO 18000-6B

- Philips UCODE EPC 1.19

- EPC Class1 Gen2 / ISO 18000-6C

SOFTWARE:

Self-installing drivers for Windows 7, 8, 8.1, 10 (32-64 bit support); Linux (32-64 bit support); Android, iOS, Windows Phone

ACCESSORIES

Vertical stacker

Roll holder for bag tag

RFID module

TECHNICAL SHEET

Printing Method Thermal with fixed head

Number of dots 8 dots/mm

Resolution 203 DPI

Printing (mm/sec) >200 mm/sec

Character set Latin, Cyrillic, Chinese

Paper width from 20 mm to 82.5 mm

Emulation Cupps compliant and native AEA 2012 support

Interfaces RS232 + USB

Data Buffer 16 KB text / 1 MB graphics

Flash Memory 3 MB

Drivers Self-installing drivers for Windows 7, 8, 8.1, 10 (32-64 bit support); Linux (32-64 bit support); Android, iOS, Windows Phone

Power supply 24 Vdc±10% , from 100 Vac to 240 Vac

Medium consumption 1.5A       (12.5% dots turned on)

Head Life 100Km / 100M pulses

Operating temperature from -10°C to +60°C

Dimensions 122.6 (L) x 85 (H) x 145.6 (W) mm

Weight 2.2 Kg
